Excavator Augers // Excavators 8T TO 22T

The Earth Drills 11000-40, 11000-45, 15000-45, and 18500-45 are the perfect choice for excavators between 8T-22T.

Over-engineered and built to last these products give you the versatility, peace of mind, and quality you expect from Auger Torque products. A 2-Way Valve is an optional extra on this series of Earth Drills and enables you to convert a single-acting hammer circuit into the 2-way auxiliary flow. For the Earth Drill 15000-45 and 18500-45, an optional Pressure Relief Valve is also available. Safeguard your investment by protecting the hydraulic motor from backpressure and hydraulic pressure spikes. High-quality hoses and couplers are standard with this series of Earth Drills (15000-45 and 18500-45 do not include couplers), type and size need to be specified at the time of purchase.

MODEL 11000-40 11000-45 15000-45 18500-45
Carrier Weight 8-13 MT 10-15 MT 13-20 MT 15-22 MT
Torque Range 2948-8847 ft-lb 3706-11116 ft-lb 9619-14428 ft-lb 12171-18257 ft-lb
Oil Pressure Range 1160-3481 psi 1160-3481 psi 1160-3481 psi 1160-3481 psi
Oil Flow Range 19-40 gpm 21-45 gpm 21-45 gpm 21-45 gpm
Speed Range 25-54 rpm 20-43 rpm 16-33 rpm 12-26 rpm
Unit Height 37 in. 37 in. 45 in. 45 in.
Unit Diameter 12 in. 12 in. 14 in. 14 in.
Unit Weight 379 lb. 382 lb. 591 lb. 593 lb.
Output Shaft Std 2.96 inch Square 2.96 inch Square 2.96 inch Square 2.96 inch Square
Hitch Options Single Pin Hitch
Double Pin Hitch
Cradle Hitch
Single Pin Hitch
Double Pin Hitch
Cradle Hitch
Single Pin Hitch
Double Pin Hitch
Cradle Hitch
Single Pin Hitch
Double Pin Hitch
Cradle Hitch
Auger Series S6 S6 S6 S6
Auger Diameter 6-48 in 6-48 in 6-48 in 6-48 in
Drilling Depth 25-12 ft 25-12 ft 28-15 ft 13-30 ft

Key Features:

Auger Torque’s Earth Drills are built to the most exacting standards using only high quality materials and the latest manufacturing techniques available.

  • FORGED HOOD EARS

    Standard with all Earth Drills in areas that we know will take a lot of strain. All hood pins are locked for extra safety making it impossible for the hood to detach from your hitch.

  • EPICYCLIC GEARBOX

    Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motor’s output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.

  • NON-DISLODGEMENT SHAFT

    Unique to Auger Torque, the Non-Dislodgement Shaft is a single-piece drive shaft assembled top down and locked into the Earth Drill housing. This design guarantees that the shaft will never fall out, making for a safer work environment, not only for the operator but also any surrounding workers, a MUST-HAVE FEATURE for any safety-conscious company.

  • HIGH-QUALITY HYDRAULIC MOTORS

    Auger Torque’s huge buying power means we work closely with high-quality suppliers to develop the most reliable attachments available on the market today.

  • HOSES AND ADAPTORS

    All Earth Drills come standard with high-quality hoses and adaptors (excludes larger units. QRC’s not included).
